| ENGINE SPECIFICATION |
| Engine Brand: |
LIFAN |
| Engine Model: |
1P52FMI |
| Engine Type: |
4 Stroke - SOHC - Single Cylinder - Air Cooled |
| Cooling System: |
Air Cool |
| Compression: |
9.3:1 |
| Bore/Stroke: |
52.4mm x 55.5mm |
| Maximum Output KW/HP: |
5.8kw / 7.78hp |
| Maximum Power / Rotating Speed: |
8.5n.m / 5000rpm |
| Front/Rear Sprocket Tooth Count: |
15/41T 420pitch |
| Starting System: |
Electric Start / Kick Start |
| Clutch Type: |
Multi Wet Clutch Plate |
| Transmission: |
4 SPEED Manual - N1234 (4Up), Start in N Gear |
| Gear Ratio: |
Primary Reduction: 3.722 |
| i1/i2/i3/i4: 2.833/1.706/1.238/0.958 |
| Carburettor: |
PZ-22 Carburettor |
| Air Filter: |
35mm Air Filter |
| Intake: |
High Performance Intake Manifold |
| Ignition: |
CDI |
| Fuel Type: |
High Octane Unleaded Fuel (93 or higher) |
| Engine Oil Grade / Capacity: |
10W/40 Mineral 4 Stroke Engine Oil / 900ml |
| Magneto Type: |
Electronic Ignition System |
| Displacement: |
125cc |
| Chain: |
SF #420 Chain |
| Spark Plug: |
A7TC Plug |
| MATERIAL |
| Frame: |
K Type Double Tube Beam |
| Plastic Kit: |
Red / White |
| Sticker: |
Red DHZ Sticker Kit |
| Kick Starter: |
Heavy Duty Kick Starter |
| Gear Shifter: |
Standard Gear Shifter |
| Fuel Tank: |
Heavy Duty 5.2L Fuel Tank, with Plastic Petrol Cap |
| Chain Roller: |
Nylon Chain Roller |
| Chain Guide: |
Heavy Duty Nylon Chain Guide |
| Chain Adjuster: |
Standard Chain Adjuster |
| Footpeg: |
Heavy Duty Steel Footpeg |
| Throttle: |
Standard Throttle Assembly |
| Levers: |
Alloy Fold Back Brake and Clutch Lever |
| Exhaust: |
Heavy Duty Aluminum Muffler |
| Handlebar: |
Heavy Duty Steel Tall Handlebar |
| Handlebar Grip: |
Soft Grip |
| Triple Clamp; |
Forged Polished Alloy Triple Clamp |
| Seat: |
Black Foam Seat |
| WHEELS AND TYRES |
| Front Tyre: |
60/100-14 Knobby Tyre |
| Front Wheel: |
1.40 x 14 Black Steel Rim with Heavy Duty Spokes & Alloy Hub Assembly, 15mm Axle |
| Front Rim Lock: |
No |
| Rear Tyre: |
80/100-12 Knobby Tyre |
| Rear Wheel: |
1.85 x 12 Black Steel Rim with Heavy Duty Spokes & Alloy Hub Assembly, 15mm Axle |
| Rear Rim Lock |
Yes |
| BRAKE SYSTEM AND SUSPENSION |
| Front Suspension : |
Inverted Forks, Non-adjustable |
| Front Brakes : |
Front Hydraulic Brake with Disc Rotor, Twin Piston Calliper |
| Front Brake Disk |
220mm |
| Rear Suspension: |
Hydraulic Rear Shock, Non-adjustable |
| Swing Arm: |
Heavy Duty Steel Swing Arm |
| Linkage: |
No |
| Rear Brakes: |
Rear Hydraulic Brake with Disc Rotor, Single Piston Callipper, Steel Bracket |
| Rear Brake Disk: |
190mm |
| Brake Pads: |
High Performance Copper Brake Pads |
| CAPACITY |
| Fuel Capacity: |
5.2L |
| Engine Oil Capacity: |
900ml |
| Tube Diameter of Muffler: |
30mm |
| DIMENSIONS |
| Handle Bar Height: |
1060mm |
| Seat Height: |
780mm |
| Ground Clearance / Wheel Base: |
250mm / 1150mm |
| Actual Size: |
1630mm (Length) x 750mm (Width) x 995mm (Height) |
| G.W. / N.W.: |
87kgs / 75kgs |
| Package Size: |
1320mm (Length) x 425mm (Width) x 640 mm (Height) |
