ENGINE SPECIFICATION |
Engine Brand: |
LIFAN |
Engine Model: |
1P52FMI |
Engine Type: |
4 Stroke - SOHC - Single Cylinder - Air Cooled |
Cooling System: |
Air Cool |
Compression: |
9.3:1 |
Bore/Stroke: |
52.4mm x 55.5mm |
Maximum Output KW/HP: |
5.8kw / 7.78hp |
Maximum Power / Rotating Speed: |
8.5n.m / 5000rpm |
Front/Rear Sprocket Tooth Count: |
15/41T 420pitch |
Starting System: |
Electric Start / Kick Start |
Clutch Type: |
Multi Wet Clutch Plate |
Transmission: |
4 Speed Semi Auto - N1234 (4Up), Start in N Gear |
Gear Ratio: |
Primary Reduction: 3.722 |
i1/i2/i3/i4: 2.833/1.706/1.238/0.958 |
Carburettor: |
PZ-22 Carburettor |
Air Filter: |
35mm Air Filter |
Intake: |
High Performance Intake Manifold |
Ignition: |
CDI |
Fuel Type: |
High Octane Unleaded Fuel (93 or higher) |
Engine Oil Grade / Capacity: |
10W/40 Mineral 4 Stroke Engine Oil / 900ml |
Magneto Type: |
Electronic Ignition System |
Displacement: |
125cc |
Chain: |
SF #420 Chain |
Spark Plug: |
A7TC Plug |
MATERIAL |
Frame: |
K Type Double Tube Beam |
Plastic Kit: |
Red / White |
Sticker: |
Red DHZ Sticker Kit |
Kick Starter: |
Heavy Duty Kick Starter |
Gear Shifter: |
Standard Gear Shifter |
Fuel Tank: |
Heavy Duty 4.5L Fuel Tank, with Plastic Petrol Cap |
Chain Roller: |
Nylon Chain Roller |
Chain Guide: |
Heavy Duty Nylon Chain Guide |
Chain Adjuster: |
Standard Chain Adjuster |
Footpeg: |
Heavy Duty Steel Footpeg |
Throttle: |
Standard Throttle Assembly |
Levers: |
Alloy Fold Back Brake Lever |
Exhaust: |
Chromium-plated iron exhaust pipe, Heavy Duty Aluminum Muffler |
Handlebar: |
Heavy Duty Steel Tall Handlebar |
Handlebar Grip: |
Soft Grip |
Triple Clamp; |
Forged Polished Alloy Triple Clamp |
Seat: |
Black Foam Seat |
WHEELS AND TYRES |
Front Tyre: |
60/100-14 Knobby Tyre |
Front Wheel: |
1.40 x 14 Black Steel Rim with Heavy Duty Spokes & Alloy Hub Assembly, 15mm Axle |
Front Rim Lock: |
No |
Rear Tyre: |
80/100-12 Knobby Tyre |
Rear Wheel: |
1.85 x 12 Black Steel Rim with Heavy Duty Spokes & Alloy Hub Assembly, 15mm Axle |
Rear Rim Lock |
Yes |
BRAKE SYSTEM AND SUSPENSION |
Front Suspension : |
Inverted Forks, Non-adjustable |
Front Brakes : |
Front Hydraulic Brake with Disc Rotor, Twin Piston Calliper |
Front Brake Disk |
220mm |
Rear Suspension: |
Hydraulic Rear Shock, Non-adjustable |
Swing Arm: |
Heavy Duty Steel Swing Arm |
Linkage: |
No |
Rear Brakes: |
Rear Hydraulic Brake with Disc Rotor, Single Piston Callipper, Steel Bracket |
Rear Brake Disk: |
190mm |
Brake Pads: |
High Performance Copper Brake Pads |
CAPACITY |
Fuel Capacity: |
4.5L |
Engine Oil Capacity: |
900ml |
Tube Diameter of Muffler: |
30mm |
DIMENSIONS |
Handle Bar Height: |
870mm |
Seat Height: |
750mm |
Ground Clearance / Wheel Base: |
250mm / 1150mm |
Actual Size: |
1630mm (Length) x 750mm (Width) x 995mm (Height) |
G.W. / N.W.: |
87kgs / 75kgs |
Package Size: |
1320mm (Length) x 425mm (Width) x 640 mm (Height) |
